AA-SUB
SUBMERSIBLE GLASSWASHER
Dim(mm): 200 L X 300 W X 280 H
4 pcs. 150 mm brush
1 pcs. 170 mm brush
Overload Safety Switch
Standard Ground Fault Protection
Power: 220 V, 60 Hz, 1/3 HP
DW-3210S
HOOD TYPE DISHWASHER
Dim(mm): 650 L X 650 W X 1355 H
Hood clearance: 350 mm
Tank Capacity: 40 L (wash), 27 L (rinse)
Speed: up to 73 racks per hour
Booster heater, detergent dispenser
Stainless steel construction with
view window
Remote controller
Power: 220 V, 60 Hz, 3 Phase, 4 kW
JW-25B
25 COMPARTMENT PLATE RACK
Dim(mm): 500 L X 500 W X 100 H
Compartment: 68 L X 68 W X 65 H
Color: Biege
JW-16
16-COMPARTMENT GLASS RACK
Dim(mm): 500 L X 500 W X 100 H
Compartment Dim: 115 L X 115 W X 45 H
Color: Biege
JW-64B
64 COMPARTMENT PLATE RACK
Dim(mm): 500 L X 500 W X 100 H
Compartment: 45 L X 45 W X 72 H
Color: Biege
DISHWASHING
COOKING
REFRIGERATION
PREPARATION
BAKERY
SERVERY
OTHERS
LAUNDRY
DISHWASHING
AND RACKS
COOKING AND
EXHAUST HOOD
WORK TABLES
AND CABINETS
CANTEEN
AND SERVERY
MAINTENANCE
CHEMICALS
BAR AND
COCKTAILS
You could also reach us
through the following:
JW-49
49-COMPARTMENT GLASS RACK
Dim(mm): 500 L X 500 W X 100 H
Compartment: 65 L X 65 W X 80 H
Color: Biege
JW-C
CUTLERY / SILVERWARE RACK
Dimension: 500 L X 500 W X 100 H
Compartment: 11 L x 11 W
Color: Biege
FCT-1
PRE-RINSE FAUCET
Dim(mm):
Deck mounted type
Riser brass pipe
Flexible stainless steel hose
Inner pipe
Wall bracket
Check valve to prevent cross-flow
BNT650T
WATER SOFTENER WITH
TIMED CONTROL VALVE
Attachment for DW-3210S Dishwasher
Operation Modes: SOFTENER,
FILTER, REGENERATION MODE
Hydrostatic Test Pressure: 350 psi
Working Pressure: 20~125 psi
Working Temperature: up to 39°C
Pressure Tank Thread: 2.5″ NPSM
Inlet /Outlet Connector: 1″, 3/4″, 1/2″
Power: 220 V, 60 Hz
